Description
The JAM Pedals Octaurus is a premium, all-analog octave-fuzz pedal engineered to deliver unbridled, devastating silicon saturation. Handcrafted in Athens, Greece, the Octaurus consolidates the finest attributes of historic octave-fuzz predecessors into a singular, highly optimized enclosure. Rather than introducing a thin, piercing, or temperamental clipping path, this pedal serves up an uncompromised, massive wall of fuzz that retains note definition and authority across your instrument's entire register.
The true genius of the Octaurus lies in its carefully calculated internal tracking network. It produces a clear, highly apparent upper octave that tracks effortlessly regardless of your selected pickup position, string gauge, or neck position. JAM Pedals designed the gain architecture to maintain absolute fundamental note body—ensuring your lower register sounds thick and full while your upper-register leads cut through dense mixes with searing, harmonic chime.
Advanced Voicing and Dual-Clipping Modes
The interface of the Octaurus provides immediate, deeply interactive tone-shaping capabilities via a straightforward knob layout and two heavy-duty toggle switches:
-
Left Toggle (Voicing Switch):
-
Scooped Mode: Applies a precise mid-range cut. This yields a raw, industrial, and aggressive fuzz texture that tightens your transients for heavy riffing and makes the upper octave effect significantly more pronounced.
-
Full Range Mode: Restores full mid-range frequency response, transforming the pedal into a smooth, singing, and endlessly sustaining lead voice that soars above a band mix.
-
Right Toggle (Clipping Switch):
-
Symmetrical Clipping: Provides a tight, compressed, and uniform clipping structure. This gives you laser-focused note definition and instantaneous string tracking.
-
Asymmetrical Clipping: Delivers a looser, more open, and dynamic distortion grain that accurately mirrors the natural sag and responsive feel of an overdriven tube power section.
Dynamic Integration & Studio Performance
Unlike finicky vintage circuits that collapse or turn to static when you adjust your instrument's onboard electronics, the Octaurus exhibits exceptional interaction with your guitar’s volume pot. Rolling back your volume control unlocks an array of distinct ring-modulation textures and clean-octave tones without sacrificing your ability to play complex double stops or open fundamental intervals. In Scooped Mode, the pedal maintains an overdrive-like string clarity, allowing full open power chords to ring out with massive girth without degenerating into absolute sonic mud.
-
Ultra-Efficient Analog Layout: Utilizing an entirely analog, low-noise signal path, the pedal draws an incredibly low 5mA of current, ensuring total compatibility with standard 9V battery operation or modern isolated pedalboard power bricks.
-
Boutique Visual Styling: Housed in JAM Pedals’ iconic, custom hand-painted chassis, featuring striking, era-correct "Bull" graphics to reflect its unbridled power.
-
Mechanical True Bypass: True bypass switching ensures that when the pedal is turned off, your dry guitar signal remains 100% unaltered and isolated from the circuit.
Tech Specs
-
Pedal Type: Premium Analog Silicon Octave-Fuzz
-
Controls: Level, Tone, Gain, 2-Way Voicing Toggle (Scooped / Full), 2-Way Clipping Toggle (Symmetrical / Asymmetrical)
-
Bypass: True Bypass
-
Input Impedance: 500 kΩ
-
Output Impedance: Less than 10 kΩ
-
Power Requirement: 9V Battery or 9V DC Adaptor (Center Negative, ~5mA current draw)
-
Dimensions: 2.9" x 4.7" x 2.2" (7.5cm x 12.0cm x 5.6cm)
-
Origin: Handbuilt and Hand-Painted in Athens, Greece
